S8050 Flat Top E (7.0 mm) High Temperature Heavy Load (HTL)

Series 8050
Request a Quote

Overcome challenging conditions in ambient to hot environments with the Intralox Series 8050 Flat Top (7.0 mm) belt in HTL.

Part of our BarDrive product line, this belting features a full-width drive bar that maximizes belt pull. Its tensionless, positive-drive system reduces downtime and eases maintenance in heavily loaded, direct food–contact applications.

Built for highly demanding applications, HTL belting pairs superior heat resistance with a pulling capacity of 1,056 lb/ft (1,572 kg/m). It reliably performs within a continuous temperature range of 60°F–210°F (15°C–100°C).

  • Pair with Intralox ZeroSplice technology to eliminate splicing needs
  • Homogeneous thermoplastic structure streamlines installation
  • Lightweight, hinge-free belting improves sanitation
inmm
Pitch1.95650
Overall Thickness0.2767.0
Minimum Width125
Maximum Width501270
Minimum Backbend Diameter6.0152
Minimum Sprocket Diameter (10T)6.5165
Open Area (seamless surface)0%
Available Joining Optionsprepared ends, endless, metal lace
Available Colorsnatural

  • Contact Intralox for precise belt measurements and stock status before designing equipment or ordering a belt.
  • Designed specifically for high temperatures and/or heavy loads.
  • For continuous use below 60°F (15°C) contact Intralox Customer Service for required minimum sprocket diameter.
  • See Material Compliance for compliance details.

Belt MaterialMaximum Belt Pull Capability1,2Temperature Range (continuous)3 Belt Weight
lbf/ft widthN/m width°F°Clb/ft2kg/m2
HTL1,05615,41160 to 21215 to 1000.884.31

  1. With sprockets spaced on 3 in (76 mm) centers; Use stacked sprockets for applications with loads greater than 50% of the maximum belt pull capability.

  2. For continuous use over 170°F (77°C), contact Intralox Customer Service for actual belt pull capability.

  3. In some applications, continuous use temperatures can exceed 210°F (100°C).
