Flat Top with Heavy-Duty Edge
Series 1600| in | mm | |
| Pitch (nominal) | 1.00 | 25.4 |
| Minimum Width | 5 | 127 |
| Width Increments | 0.50 | 12.7 |
| Opening Size (approximate) | — | — |
| Open Area | 0% | |
| Hinge Style | Open | |
| Rod Retention; Rod Type | Occluded edge; unheaded | |
- Contact Intralox for precise belt measurements and stock status before designing equipment or ordering a belt.
- Smooth, closed upper surface with flush edges.
- Heavily reinforced and carefully sculpted edge is designed to resist belt snagging and edge damage while maintaining cleanability.
- No pockets or sharp corners to catch and hold debris.
- Cam-link hinges provide easy cleaning with greater hinge and rod exposure as the belt moves around the sprockets. This exclusive Intralox feature allows unsurpassed cleaning access to this area.
- Compatible with Intralox belt tensioners. See Intralox Belt Tensioners for more information.
- The drive bar on the underside of this belt channels water and debris to the outside of the belt for easier, faster cleanup. Drive bar effectiveness is proven both in-house and in field tests.
- Minimum sprocket indent from belt edge: 1.25 in (31.75 mm) to sprocket centerline
- Each belt material has a default rod material. Other rod materials are available. Intralox can help identify the best belt and rod material combination for your application.
- Detailed material information is provided in Product Line.
- No-Cling flights are available.
- Standard flight height: 4 in (102 mm).
- Custom flight heights are available. Contact Intralox Customer Service for more information.
| Belt Material | Default Rod Material, Diameter 0.18 in (4.6 mm) | Belt Strength | Temperature Range (continuous) | Belt Mass | |||
|---|---|---|---|---|---|---|---|
| lbf/ft | N/m | °F | °C | lb/ft² | kg/m² | ||
| Acetal | PK | 1,000 | 14,600 | -40 to 176 | -40 to 80 | 1.58 | 7.71 |
| PK | PK | 1,000 | 14,600 | -40 to 176 | -40 to 80 | 1.39 | 6.79 |
