Flat Top with Heavy-Duty Edge

Series 1800

Minimize foreign material risks in the harshest meat and poultry applications with the Intralox Series 1800 Flat Top with Heavy-Duty Edge (HDE) belt.

This belt features a patented, fault-tolerant edge that protects against edge breakage, mitigating foreign material risks. Equipped with a drive bar on its underside that guides debris away from the belt, it easily handles challenging products with its abrasion-resistant link design.

2.5-in (63.5-mm) pitch increases belt strength
Closed surface prevents product loss
Available in impact- and abrasion-resistant materials
HDE reduces foreign material risk and unscheduled downtime

	in	mm
Pitch	2.50	63.5
Minimum Width	7.00	177.8
Width Increments	1.00	25.4
Opening Size	-	-
Open Area	0%
Hinge Style	Open
Rod Retention; Rod Type	Occluded edge; unheaded

Contact Intralox for precise belt measurements and stock status before designing equipment or ordering a belt.
Smooth, closed upper surface with fully flush edges.
Impact-resistant belt designed for abusive applications.
Like S800 and S1600, the drive bar on the underside of this belt channels water and debris to the outside of the belt for easier, faster cleanup. Drive bar effectiveness is proven both in-house and in field tests.
Cam-link hinges provide easy cleaning with greater hinge and rod exposure as the belt moves around the sprockets. This exclusive Intralox feature allows unsurpassed cleaning access to this area.
Heavily reinforced and carefully sculpted edge is designed to resist belt snagging and edge damage while maintaining cleanability.
Compatible with Intralox belt tensioners. See Intralox Belt Tensioners for more information.
Each belt material has a default rod material. Other rod materials are available. Intralox can help identify the best belt and rod material combination for your application.
Detailed material information is provided in Product Line.
Easy retrofit from Series 800 without extensive conveyor frame changes for most meat industry applications since the A, B, C, and E dimensions are within 0.25 in (6 mm) of S800.

Belt Material	Default Rod Material, Diameter 0.31 in (7.9 mm)	Belt Strength		Temperature Range (continuous)		Belt Mass
Belt Material	Default Rod Material, Diameter 0.31 in (7.9 mm)	lbf/ft	N/m	°F	°C	lb/ft²	kg/m²
Polypropylene	Polypropylene	1,200	17,500	34 to 176	1 to 80	2.06	10.06
Acetal	Polyethylene	1,200	17,500	-50 to 150	-46 to 66	3.36	16.40
Acetal	PK	1,500	21,900	-40 to 176	-40 to 80	3.36	16.40
PK	PK	1,200	17,500	-40 to 176	-40 to 80	3.02	14.74
